Beater cutter mower DSB DITTA-SERIA
The Ditta-Seria DSB line of mulchers are devices designed for chopping branches cut in gardens and fields, for destroying the remains of vegetables, corn, weeds, as well as cutting grass.
The design of the machine allows you to crush branches with a diameter of up to 7 cm.
The main working element is the rotor, fixed horizontally in relation to the base.
Massive beaters are installed on the rotor. An additional advantage is the double lining of the machine body with 4 mm thick sheet metal, which prevents deformation.
The solid design of our mowers is evidenced by their large dead weight.
Specifications:
Model
DSB*
Working Width, cm
from 130 to 180
Total Width
from 164 tо 215
Weight
from 460 to 1889
N. of knives
from 14 to 16
shop-item-turnovers
540
Power, h.p.
from 40 to 70
- Adjustment of work height – two-stage
- Hydraulic lateral shift
- Easy access to replace hammers
- Lateral V-belts
- Rear hinge with two-position adjustment
- Shredding of branches up to 7 cm
- Reinforced frame structure (metal thickness – 4.0 mm)
* It is possible to supply Ditta-Seria harvester choppers with a hopper for collecting chopped branches.
